91 ACS2000 AFE 2MVA UM 3BHS355653 ZAB E01 REV. H
—
6.5 Terminal sizes
The auxiliary power and I/O module terminals are described below.
—
Table 6-1 Auxiliary power terminal sizes
Standard three-phase auxiliary power supply
Terminal
Wire cross section (mm
2
)
Solid wire Flexible wire
-X1:1
2.5 to 25
-X1:3
-X1:5
-N
-PE
Optional single-phase UPS
Terminal
Wire cross section (mm
2
)
Solid wire Flexible wire
-X1:11
1.5 to 25
-X1:12
-PE
Optional auxiliary power supply for converter space heater
Terminal
Wire cross section (mm
2
)
Solid wire Flexible wire
-X1:15
1.5 to 25
-X1:16
-PE
—
Table 6-2 I/O module terminal sizes
Wire cross section (mm
2
)
Solid wire Flexible wire
Digital inputs
0.5 to 2.5
Digital outputs
Analog inputs
Analog outputs
!
For information on the auxiliary supply
voltage, see the rating label of the drive.
