Parameters 165
05.42 Aux. fan service
counter
Displays the age of the auxiliary cooling fan as a percentage
of its estimated lifetime. The estimate is based on the duty,
operating conditions and other operating parameters of the
fan. When the counter reaches 100%, a warning (A8C0 Fan
service counter) is generated.
Can be reset from the control panel by keeping Reset
depressed for over 3 seconds.
-
0…150% Auxiliary cooling fan age. 1 = 1%
05.111 Line converter
temperature
(Only visible when IGBT supply unit control activated by
95.20)
Estimated supply unit temperature in percent of fault limit.
0.0% = 0 °C (32 °F)
94% approx. = Warning limit
100.0% = Fault limit
-
-40.0 … 160.0% Supply unit temperature in percent. 1 = 1%
05.121 MCB closing
counter
(Only visible when IGBT supply unit control activated by
95.20)
Counts the closures of the main circuit breaker of the supply
unit.
-
0…4294967295 Count of closures of main circuit breaker. 1 = 1
06
06 Control and status
words
Drive control and status words.
06.01 Main control word The main control word of the drive. This parameter shows the
control signals as received from the selected sources (such
as digital inputs, the fieldbus interfaces and the application
program).
The bit assignments of the word are as described on page
637. The related status word and state diagram are presented
on pages 638 and 639 respectively.
Note: Bits 12…15 can be used to carry additional control
data, and used as a signal source by any binary-source
selector parameter.
This parameter is read-only.
-
0000h…FFFFh Main control word. 1 = 1
06.02 Application control
word
The drive control word received from the application program
(if any). The bit assignments are described on page 637.
This parameter is read-only.
-
0000h…FFFFh Application program control word. 1 = 1
06.03 FBA A transparent
control word
Displays the unaltered control word received from the PLC
through fieldbus adapter A when a transparent
communication profile is selected eg. by parameter group 51
FBA A settings. See section Control word and Status word
(page 634).
This parameter is read-only.
-
00000000h …
FFFFFFFFh
Control word received through fieldbus adapter A. -
No. Name/Value Description Def/FbEq16
