470 Additional parameter data
33.24 On-time 2 warn message uint32 --1 = 1
33.30 Edge counter 1 actual uint32 0…4294967295 - 1 = 1
33.31 Edge counter 1 warn limit uint32 0…4294967295 - 1 = 1
33.32 Edge counter 1 function uint16 0000b…1111b - 1 = 1
33.33 Edge counter 1 source uint32 --1 = 1
33.34 Edge counter 1 divider uint32 1…4294967295 - 1 = 1
33.35 Edge counter 1 warn message uint32 --1 = 1
33.40 Edge counter 2 actual uint32 0…4294967295 - 1 = 1
33.41 Edge counter 2 warn limit uint32 0…4294967295 - 1 = 1
33.42 Edge counter 2 function uint16 0000b…1111b - 1 = 1
33.43 Edge counter 2 source uint32 --1 = 1
33.44 Edge counter 2 divider uint32 1…4294967295 - 1 = 1
33.45 Edge counter 2 warn message uint32 --1 = 1
33.50 Value counter 1 actual real32 -2147483008 …
2147483008
-1 = 1
33.51 Value counter 1 warn limit real32 -2147483008 …
2147483008
-1 = 1
33.52 Value counter 1 function uint16 00b…11b - 1 = 1
33.53 Value counter 1 source uint32 --1 = 1
33.54 Value counter 1 divider real32 0.001 … 2147483.000 - 1000 = 1
33.55 Value counter 1 warn message uint32 --1 = 1
33.60 Value counter 2 actual real32 -2147483008 …
2147483008
-1 = 1
33.61 Value counter 2 warn limit real32 -2147483008 …
2147483008
-1 = 1
33.62 Value counter 2 function uint16 00b…11b - 1 = 1
33.63 Value counter 2 source uint32 --1 = 1
33.64 Value counter 2 divider real32 0.001 … 2147483.000 - 1000 = 1
33.65 Value counter 2 warn message uint32 --1 = 1
35 Motor thermal protection
35.01 Motor estimated temperature real32 -60 … 1000 °C or °F 1 = 1°
35.02 Measured temperature 1 real32 -60 … 1000 °C,
-76 … 1832 °F,
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.03 Measured temperature 2 real32 -60 … 1000 °C,
-76 … 1832 °F,
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
35.04 FPTC status word uint16 0000h…FFFFh - 1 = 1
35.05 Motor overload level real32 0.0 … 300.0 % 10 = 1%
35.11 Temperature 1 source uint16 0…11 - 1 = 1
35.12 Temperature 1 fault limit real32 -60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
°C, °F or
ohm
1 = 1 unit
