82 Installation instructions
2
5
8
3AXD5000023536
4
1
6
9
10
3
7
11
Option +H381 box: Input power
cabling panel parts
1 Screw package
2 Paper fill
3 Code label
4 Output power cabling panel
5 Input power cabling panel
6 Grounding busbar to be
connected to the input power
cabling panel and the drive
module
7 Cardboard box bottom
8 Cardboard box cover
9 Rubber grommet
10 Strap
11 Support bracket
12 Top guide
3AXD5000009515
2
6
7
5
4
3
1
Output connection terminals box
with standard drive module
configuration
1 Paper fill
2 Output cable connection terminal
T3/W2
3 Output cable connection terminal
T2/V2
4 Output cable connection terminal
T1/U2
5 Grounding terminal
6 Cardboard box
7 Screws and insulators a plastic
bag
