APPENDIX E
CIRCUIT BREAKER RENEWAL PARTS AND ACCESSORIES:
The parts listed below are available from ABB for field use or replacement. Consult your ABB sales representative for
current pricing and availability.
Part # Qty/Breaker Description
14020P00 1 CHARGING HANDLE
14024G00 1 RACKING HANDLE ASSEMBLY
14038G00 1 LIFTING HOOK ASSEMBLY (CHAIN)
14039G00 1 ACCESSORY KIT (14020P00, 14024G00, and 14038G00)
713222A00 NA LUBRICANT: NO-OX-ID (1 pt Can)
712994A00 NA LUBRICANT: Anderol 757 (4oz Tube)
ACCESSORIES:
Part # Qty/Breaker Description
18006P10 1 CHARGING MOTOR (120VAC/125VDC)
18006P20 1 CHARGING MOTOR (240VAC/250VDC)
18006P30 1 CHARGING MOTOR(48VDC)
715668A00 1 MOTOR DISCONNECT SWITCH
11142G00 1 OPERATION COUNTER ASSEMBLY
16008G00 1 ADVAC LABEL KIT
16016G00 1 FRONT PLATE ASSEMBLY (W/O RATING LABEL)
MECHANISM:
Part # Qty/Breaker Description
15000G00 1 TRUCK ASSEMBLY (EXTENDED, 36” WIDE, “MOD2” BREAKERS)
15100G00 1 TRUCK ASSEMBLY ( 36” WIDE, “MOD1” BREAKERS)
15100G10 1 TRUCK ASSEMBLY (EXTENDED, 36” WIDE, “MOD1” BREAKERS)
715668A00 1 MOTOR DISCONNECT SWITCH
15070P00
15069P00
16965P00
16907P00
4
4
4
4
WHEEL
AXLE BUSHING
BOLT
LOCKWASHER
TRUCK: (BREAKERS ONLY)
