42/24-12-2 EN Advance Optima Ex Analyzer Modules Operator’s Manual 7
Unpack and Install the Ex Analyzer Module, continued
Ex Analyzer Module
Installation
4 M8 bolts (not supplied) are needed to install the Ex analyzer module.
Caldos 15-Ex
Magnos 106-Ex
The Caldos 15-Ex and Magnos 106-Ex analyzer modules must be installed with
their housings in the vertical position and their connection ports facing down.
Caldos 17-Ex
Uras 14-Ex
The housings of the Caldos 17-Ex and Uras 14-Ex analyzer modules can be
installed in the vertical or horizontal position.
• If installed vertically the ports must face downward.
• For horizontal installation the O-ring supplied (∅ 220 x 3 mm) must be installed in
the slot provided between the housing floor and the housing.
• If the Uras 14-Ex analyzer module is installed horizontally it is preferable to orient
the housing so that the identification plate faces up.
