ABB AMI Series User Manual

Manual for Induction Motors and Generators
Trouble Shooting - 107
3BFP 000 050 R0101 REV E
Table 8-1. Temperature values for Pt-100 elements
PT100
RES :
TEMP
°C
TEMP
°F
PT100
RES :
TEMP
°C
TEMP
°F
PT100
RES :
TEMP
°C
TEMP
°F
100.00 0
32.00
127.07 70 158.00 153.58 140 284.00
100.78 2
35.60
127.84 72 161.60 154.32 142 287.60
101.56 4
39.20
128.60 74 165.20 155.07 144 291.20
102.34 6
42.80
129.37 76 168.80 155.82 146 294.80
103.12 8
46.40
130.13 78 172.40 156.57 148 298.40
103.90 10
50.00
130.89 80 176.00 157.31 150 302.00
104.68 12
53.60
131.66 82 179.60 158.06 152 305.60
105.46 14
57.20
132.42 84 183.20 158.81 154 309.20
106.24 16
60.80
133.18 86 186.80 159.55 156 312.80
107.02 18
64.40
133.94 88 190.40 160.30 158 316.40
107.79 20
68.00
134.70 90 194.00 161.04 160 320.00
108.57 22
71.60
135.46 92 197.60 161.79 162 323.60
109.35 24
75.20
136.22 94 201.20 162.53 164 327.20
110.12 26
78.80
136.98 96 204.80 163.27 166 330.80
110.90 28
82.40
137.74 98 208.40 164.02 168 334.40
111.67 30
86.00
138.50 100 212.00 164.76 170 338.00
112.45 32
89.60
139.26 102 215.60 165.50 172 341.60
113.22 34
93.20
140.02 104 219.20 166.24 174 345.20
113.99 36
96.80
140.77 106 222.80 166.98 176 348.80
114.77 38
100.40
141.53 108 226.40 167.72 178 352.40
115.54 40
104.00
142.29 110 230.00 168.46 180 356.00
116.31 42
107.60
143.04 112 233.60 169.20 182 359.60
117.08 44
111.20
143.80 114 237.20 169.94 184 363.20
117.85 46
114.80
144.55 116 240.80 170.58 186 366.80
118.62 48
118.40
145.31 118 244.40 171.42 188 370.40
119.40 50
122.00
146.06 120 248.00 172.16 190 374.00
120.16 52
125.60
146.81 122 251.60 172.90 192 377.60
120.93 54
129.20
147.57 124 255.20 173.63 194 381.20
121.70 56
132.80
148.32 126 258.80 174.37 196 384.80
122.47 58
136.40
149.07 128 262.40 175.10 198 388.40
123.24 60
140.00
149.83 130 266.00 175.84 200 392.00
124.01 62
143.60
150.57 132 269.60 176.57 202 395.60
124.77 64
147.20
151.33 134 273.20 177.31 204 399.20
125.54 66
150.80
152.04 136 276.80 178.04 206 402.80
126.31 68
154.40
152.83 138 280.40 178.78 208 406.40
