2-14 MN1240
Feedback Devices Continued
Encoder
120˚e
120˚e
180˚e
±1˚m
(90˚)e
CH
. A
90˚e typ. (45˚e min.)
90˚e typ. (45˚e min.)
90˚e typ. (45˚e min.)
90˚e typ. (45˚e min.)
CH
. B
CH
. Z
CH
. U
CH
. U
CH
. V
CH
. W
Encoder specifications
Power in 5V
Output Line driver
Incremental 2 channel
Index
Hall output (4 or 8 pole)
PPR STD 2500 ppr
Contact ABB for other options
Maximum Electrical
Frequency
1000/2500 ppr
200 kHZ/300kHZ
Hall output BSM/SSBSM 50/63/80 series use 4
pole Hall output. 90/100/132 series
use 8 pole Hall output.
Operating temperature
range
-20° C to +120° C
= U
= V
= W
Hall sensor specifications
Power in 3.8-30 Vdc
Output Hall output (4 or 8 pole)
