ABB BSM50N - Brushless Servo Motor Model Identification; Motor Identification Coding

2-15MN1240
Brushless Servo Motor Identification
Frame
IEC
50
63
80
90
100
132
Series
N
C
S MB
Winding code
1
2
3
4
50
75
etc.
Motor size
Motor options
- A = Resolver
- B = Absolute encoder - single-turn (BiSS)
- B2 = Absolute encoder - multi-turn (BiSS)
- D = Absolute encoder - multi-turn (EnDat)
- D2 = Absolute encoder - single-turn (EnDat)
- D3 = Absolute encoder - single-turn (Hiperface)
- D4 = Absolute encoder - multi-turn (Hiperface)
- S1 = Absolute encoder - single-turn (SSI)
- S2 = Absolute encoder - multi-turn (SSI)
- E = Incremental encoder w/ commutation (1000 ppr)
- F = Incremental encoder w/ commutation (2500 ppr)
- H = Halls only
- V = Resolver mounting only
Accessory options
Description
Connections
Motor (no shaft seal) A
E I
Motor and brake B
F
J
Motor with shaft oil seal
C
G
K
D
H
L
- Blank = No option
- M = No keyway
- N = DIN 42955-R
- O = DIN 42955-R & no keyway
- P = Optional motor connector on BSM 90/100
(Note: This option available only if current less that 28 amps)
- X = Special option (order by spec no. only)
- Z1 = Blower (115 VAC) (not available on all motors)
- Z2 = Blower (230 VAC) (not available on all motors)
-Z3 = Blower (24 Vdc)
-Z4 = Blower (230/460 VAC) for BSM132 only
Feedback options
Blank = Std
SS = Stainless steel
Note: Not all options are
available on all motors.
Contact ABB.
NEMA
5N
6N
8N
9N
10N
Standard (metric)
threaded style
Cables
Flying
leads
Optional (inch)
quick connect
Rotate-able
(metric)
threaded
Motor with brake & shaft oil seal
M
N
O
P
R
S
T
U
Note:
1. The standard BSM50/63/80 series includes feedback, two threaded connectors for feedback and motor terminations,
square mounting flange.
2. The standard BSM90/100 series includes, one threaded connector for feedback termination, termination of motor lead
wires on terminal block, square mounting flange.
3. BSM motors do not have shaft seal as standard. BSM motors are IP54. Motors will meet IP55 with shaft oil seal.
4. SSBSM motors available with IEC mounting and include as standard a shaft seal. SSBSM motors are IP67.
5. The standard BSM50 series has as standard no keyway.
6. Shielded cables and flying leads are one meter long as standard. Flying leads option is composed of individual wires
with no armored protection.
7. Order motor power and feedback cable assemblies as separate items.
8. Motors may be used with 115/230/400/460 volt controls. Verify that maximum speed is not exceeded.
9. Rotatable connectors not available on BSM50-series. Standard rotatable on models up to BSM100 available (only if
current is less than 28 amps). BSM132 requires a larger connector.
10. Pricing for NEMA versions 5N, 6N, 8N, 9N, and 10N is the same as IEC versions 50, 63, 80, 90, and 100.
11. Contact your local ABB district office for special options.
