CONNECTION DIAGRAMS SENTRY
41 Back to table of contents
Pre-reset
CH1
MODE
CH2
Jokab Safety
TSR10SENTRY
CH1 CH2
CH1 CH2
CH1
MODE
CH2
Jokab Safety
USR10SENTRY
Reset
+24V
OSSD1 0V OSSD2
Info
Adam M12-5
OSSD-Info
Eva
General Code
PLe
According to
EN ISO 13849-1
Note: The stated PL is only valid if all relevant requirements according to EN ISO 13849-1/-2 are met. It is the responsibility of the
machine builder to make a risk assessment and make sure that the appropriate functional safety levels are achieved.
SMILE 11 RA SMILE 11 RA
