ABB BSR10 - Page 47

CONNECTION DIAGRAMS SENTRY
47 Back to table of contents
A
B
A
B
Safety outputs
PLUTO
CH1 CH2
CH1
MODE
CH2
Jokab Safety
USR10SENTRY
CH1 CH2
CH1
MODE
CH2
Jokab Safety
USR10SENTRY
PLe
According to
EN ISO 13849-1
Note: The stated PL is only valid if all relevant requirements according to EN ISO 13849-1/-2 are met. It is the responsibility of the
machine builder to make a risk assessment and make sure that the appropriate functional safety levels are achieved.
