10 User's manual UBB | 1ZSE 5492-156 en, Rev. 4
101 4 568 83 2 97 11
12
15
14 13 16
1. Locking device prepared for padlock
2. Emergency stop
3. Air vent
4. LOCAL/REMOTE switch
5. RAISE/LOWER switch
6. Outgoing shaft
7. Lamp (40 W socket E27)
8. Lifting eye
9. Counter
10. Tap-change in progress indicator
11. Position indicator with drag hands for max. and min.
position
12. Shaft for hand crank
13. Protective motor switch
14. Door-operated switch for lamp
15. Hand crank
16. Descriptions and circuit diagram
Cabinet layout of motor-drive mechanism, type BUE.
