8 User's manual UBB | 1ZSE 5492-156 en, Rev. 4
16
18
17
19
20
21
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Layout of on-load tap-changer, type UBB.
1. Bevel gear
2. Lifting eye
3. Flange
4. Cylinder
5. Change-over selector moving contacts
6. Change-over selector fixed contacts
7. Selector switch fixed contacts
8. Selector switch moving contacts
9. Selector switch shaft
10. Bottom drain screw
11. Bottom
12. Valve R½” for filling and draining of oil
13. Top cover
14. Connection to conservator
15. Pressure relay
16. Air release valve to transformer tank
17. Air release valve for tap-changer
18. Position indicator window
19. Current collector terminal
20. Transition resistor
21. Shielding rings
