ABB C11

Meter Settings
C11 24 2CMC486001M0201
User Manual Revision: A
5.2 Setting the Alarm
About the alarm
The alarm function gives the user the possibility to set an alarm that will trigger
when a defined limit is reached by the measured value. See table for more infor-
mation.
If the value is set above the max range, the meter will automatically set the value
to the max value allowed by the range.
Example: Alarm current is set to 100.0 A by the user, but the max value is 40.0
A, so the meter will use the max value, in this case 40.0 A.
If an alarm has been set, the output state will indicate if the alarm is triggered (AL
On) or not (AL OFF). The magnitude of the set alarm is also displayed in the
output state.
Set alarm
To set an alarm, perform the following steps when located in the view menu.
Choice in menu Unit Output on display Range
Alarm power W AL P
VV
0-9999 W
Alarm voltage V AL VOL
V
0-299.0 V
Alarm current A AL CUr
A
0-40.00 A
Alarm power factor - AL PF
C
0-1.000
Step Action Comment
1 Use the long press to get to the set menu -
2 Use the long press to get to the selection of
function menu
-
3 Toggle through the menu to choose what mag-
nitude to set. Choose one of the following:
Alarm power (W), Alarm voltage (V), Alarm
current (A) and Alarm factor (no magnitude).
Use the long press to choose.
4 Set the alarm value that the measured value
must pass in order for the alarm to trigger
(Alarm level on).
Use the short press to change
the value of the digit, and the
long press to step through the
different digits.
5 Set the time frame that the measured value
must pass the set alarm value in order for the
alarm to trigger (Alarm on delay).
Use the short press to change
the value of the digit, and the
long press to step through the
different digits.
6 Set the alarm value that the measured value
must pass in order for the alarm to be cleared
(Alarm level off).
Use the short press to change
the value of the digit, and the
long press to step through the
different digits.
