ABB EBN861 - Fuses

Commissioning and service field (ISF)
OI/PME/LME/EAN823/EBN853/EBN861-EN 33
6.3 Fuses
Electronics Fuse type Dimensions Installation
location
U=115 V U=230 V
External fuse - External 16 A; time-lag
Mains fuse 5 x 20 mm in connection
chamber
6.3 A;
time-lag
3,15 A; time-
lag
Analog setpoint 5 x 20 mm in connection
chamber
40 mA, fast-acting
EAI823 /
EAN823
Heater (optional) 5 x 20 mm in connection
chamber
2 A; time-lag
External fuse - External 16 A; time-lag
Mains fuse 5 x 20 mm in connection
chamber
12.5 A;
time-lag
10 A; time-
lag
Analog setpoint 5 x 20 mm in connection
chamber
40 mA, fast-acting
Brake fuse 5 x 20 mm Power board 0.315 A; medium time-
lag
DC link fuse 6.3 x 32 mm Power board 10 A, super fast-acting
EBN853
Heater (optional) 5 x 20 mm in connection
chamber
2 A; time-lag
External fuse
1)
- External 35 A fuse
16 A thermal
circuit
breaker
Brake fuse 5 x 20 mm Power board 0.315 A;
medium
time-lag
DC link fuse 6.3 x 32 mm Power board 16 A, super
fast-acting
Fuse for digital
outputs DO 1,DO 2,
DO 3
5 x 20 mm in connection
chamber
3 x 0.2 A,
medium
time-lag
EBN861
Heater (optional) 5 x 20 mm in connection
chamber
2 A; time-lag
1) The 35 A safety fuse and the 16 A thermal circuit breaker are included in the delivery scope. The special starting
conditions of the EBN861 power electronic unit help to ensure safe operation.
