ABB Emax E1 - Page 54

L6555
Emax
54/74
Doc. no.
Model
Apparatus
Scale
Page No
1SDH000460R0002
A B
E1
400 490
E2
400 490
E3
500 630
E4
700 790
E4/f
- 880
E6
1000 1130
E6/f
- 1260
Tightening torque of the main terminals: Nm 70
Tightening torque of the earthing screw: Nm 70
Compartment dimensions Compartment door drilling
High resistance M12 screw
Quantity per terminal
PHASE NEUTRAL
N° 2 holes for
IP54 protection
Depth
3 POLES
4 POLES
Fixed circuit-breaker
Fig. 39
Holes for passing through fl exible cables
for mechanical interlocks
