ABB Emax E1 - Page 62

L6555
Emax
62/74
Doc. no.
Model
Apparatus
Scale
Page No
1SDH000460R0002
E1
180 180
E2
180 180
E3
234 234
E4
270 360
E4/f
- 360
E6
360 486
E6/f
- 486
Fixed version
Withdrawable version
Minimum distance between the circuit-breaker and the switchgear wallDoor drilling
Compartment door mechanical lock
Fig. 47
A
3 POLES 4 POLES
