ABB Emax User Manual

6
7
2 Nm
Usare la leva "A"
Use lever "A"
Hebel "A" verwenden.
Utiliser le levier "A ".
Utilice la palanca "A".
8
2 Nm
Serrare dado e controdado a 2 Nm.
Tighten the nut and lock nut to 2 Nm.
Mutter und Kontermutter mit 2 Nm festziehen.
Serrer écrou et contre-écrou à 2 Nm.
Apriete la tuerca y la contratuerca con
un par de 2 Nm.
Quota importante
Important measurement
Wichtiges Maß
Cote importante
Cota importante
40±0.5
Emax
Emax
Emax
Cavo Z1
Bowden wire Z1
Bowdenzug Z1
Câble Bowden Z1
Cable Bowden Z1

ABB Emax Specifications

General

Rated Current	630 A to 6300 A
Number of Poles	3 or 4
Frequency	50/60 Hz
Mounting	Fixed or withdrawable
Standards	IEC 60947-2
Trip Unit	Electronic
