Operation Manual / 4 Product description / A150-M.. - A155-M..
12
Spare parts
Page 115 /
120
© Copyright 2017 ABB. All rights reserved.
HZTL4032_EN
Revision F
January 2017
Part number
Designation
- - Cartridge group
42012 (in the customer spare part set) O-ring
42167 Orifice
42170 Bearing casing insulation
42190 Expansion sleeve
42191 Threaded rod
42193 Centering bush
42195 (in the customer spare part set) O-ring
42196 Oil orifice
42200 (in the customer spare part set) O-ring
42201 Clamping nut
51000 Turbine casing
51002 Fastening strip
51010 Bearing casing insulation
51105* Metal C-ring
51500 Burst protection
56001 Nozzle ring
56005 Lamellar sealing ring
57002 Gas outlet flange
57003* Metal C-ring
57210 Burst ring
61001 Gas outlet casing
61002 (in the customer spare part set) Gasket
61301* Support
72000 Compressor casing
72011 Hexagon-head screw
72012 Fastening strip
72060 Hood
72061 Insulating bush
77000 Wall insert
77005 (in the customer spare part set) O-ring
79000 Diffuser
79040 Fixing disc
79041 (in the customer spare part set) Counter-sunk screw
81000 Filter silencer
81010 (in the customer spare part set) O-ring
82000 Air suction branch
82010 (in the customer spare part set) O-ring
86505* Speed sensor
