Operation Manual / TPL67-C.. - TPL71-C..
8 Disassembly and assembly / 8.7 Installing cartridge group
© Copyright 2018 . All rights reserved. HZTL2488_EN Revision E April 2018
u Measure and note the axial clearance (A) (see the section on axial
clearance).
CAUTION
If the axial clearance (A) is out of tolerance, an ABB Turbocharger ser-
vice station must be contacted.
u Connect oil pipes and all air lines in accordance with enginebuilder
specifications.
Version with compressor wheel cooling system
u Fit the air supply line. (See also chapter entitled Preliminary remarks /
Layout and functionality)
u Fit the filter silencer or air suction branch.
u Fit the insulation.
Page 99 / 125
