1.6 Locations of the rating plates
Fig.4: Locations of the rating plates
One rating plate (01) each is attached on the left and the right side of the foot of the tur-
bocharger.
On turbochargers with insulation supplied by ABB, at least one additional rating plate is at-
tached to the insulation of the gas outlet casing.
