8 Disassembly and assembly
8.1 Introduction
Precondition for the work described below is a turbocharger removed
from the engine (refer to the chapter entitled Removal and Installation).
CAUTION
Further work
Only the work described in this Operation Manual may be carried out.
Incorrectly performed disassembly and assembly of the cartridge
group can lead to serious machine damage.
u ABB Turbocharging recommends having further work carried out
only by trained personnel from an ABB Turbocharging Service Sta-
tion.
u Mark the casing position for assembly.
Identifying assembly devices
Not all assembly devices are marked with a part number. They can be
identified using the tool list. This list is enclosed in the toolbox.
WARNING
Maintaining assembly devices
Assembly devices must be checked for damage before and after use.
u Visually check for corrosion, cracks, deformation and wear.
u Don't use damaged assembly devices, but replace them.
Customer spare part set
Before beginning work, ensure that the required customer spare part
sets are available.
u See chapter Spare parts.
