Advant Controller AC 31 / Issued: 01.99 7 – 7 Diagnosis
3
Class 1 error descriptions
Error number in
MW 254,00
Dec Hex
Detailed info 1 in
MW 254,01
Detailed info 2 in
MW 254,02
Detailed info 3 in
MW 254,03
Flash EPROM checksum error - - - -
-
Class 2 error descriptions
Error number in
MW 254,08
Dec Hex
Detailed info 1 in
MW 254,09
Detailed info 2 in
MW 254,10
Detailed info 3 in
MW 254,11
Defective RAM (user program or
data memory)
128
D
80
H
Memory address - -
Too many simultaneous timers
active on the basic unit during
program execution (maximum 42)
255
D
FF
H
---
Class 3 error descriptions
Error number in
MW255,00
Dec Hex
Detailed info 1 in
MW 255,01
Detailed info 2 in
MW 255,02
Detailed info 3 in
MW 255,03
Remote unit disconnected 15
D
0F
H
Unit type Address
-
CS31 system bus error (no remote
units connected to the bus)
Note: If there are only analog units
connected to the CS31 system bus,
then this error could occur when
powering up while the analog units
are not initialized.
Reason: Analog units have a fairly
long initialization period. They are
therefore not recognized by the
basic unit during this initialization
phase.
16
D
10
H
---
NCB or NCBR error
Note: Error on one of the CS31
lines. Check the red status LED of
NCB or NCBR to locate the
defective line.
17
D
11
H ---
Superposed address 18
D
12
H
Cycle time too short 200
D
C8
H ---
