4.5.4 Summary
Master basic unit
40 and 50 series
Addresses Address configuration
- Integrated inputs/outputs 62 Standard
- Digital extension 63 to 68 automatically
- Analog extension 63 to 68 automatically
Remote
unit
Addresses X N
Where X = address of the extensible remote unit,
and N = maximum number of extensions of one type on an extensible remote unit.
Master basic unit Address configuration
50 series 90 series
- Extensible remote unit, By rotary switches
If solely digital extension
0 ≤ X+N ≤ 61 0 ≤ X+N ≤ 61
automatically
If at least one analog extension
0 ≤ X ≤61 0 ≤ X ≤5
automatically
- 50 series slave basic unit
Digital configuration 0 to 61 0 to 61 by programming software
KW00,00
Analog configuration 0 to 61 0 to 5 by programming software
KW 00,00
- 90 series slave basic unit
Digital configuration 0 to 61 0 to 61 by programming software
KW 00,00
Analog configuration 0 to 5 0 to 5 by programming software
KW 00,00
