Advant Controller AC 31 / Issued: 01.99 1 – 9 Introduction
3
Products Description Order no.
Centrally extensible remote units
with CS31 bus connection
Only for 50 and 90 series basic units
ICMK 14 F1 24VDC Extensible remote unit
with 8 inputs and 6 relay outputs,
24 V d.c. power supply
1SBP260050R1001
ICMK 14 F1 120/230VAC Extensible remote unit
with 8 inputs and 6 relay outputs,
120/230 V AC power supply
1SBP260051R1001
ICMK 14 N1 24VDC Extensible remote unit
with 8 inputs and 6 transistor outputs,
24 V d.c. power supply
1SBP260052R1001
Central extensions without CS31
bus connection
For 40 and 50 series basic units and centrally extensible
remote units with CS31 bus connection
XI 16 E1 Digital extension
with 16 isolated inputs,
powered by the basic unit or remote unit
1SBP260100R1001
XO 08 R1 Digital extension
with 8 relay outputs,
powered by the basic unit or remote unit
1SBP260101R1001
XC 08 L1 Digital extension
with 8 channels, configurable as inputs or transistor outputs,
24 V d.c./0.5 A,
powered by the basic unit or remote unit
1SBP260102R1001
XK 08 F1 Digital extension
with 4 inputs and 4 relay outputs,
powered by the basic unit or remote unit
1SBP260102R1001
XM 06 B5 Analog extension
with 4 inputs configurable for current/voltage/Pt 100/Pt 1000)
and 2 outputs configurable for current/voltage resolution 12
bits,
powered by the basic unit or remote unit
1SBP260103R1001
30 series digital remote units with
CS31 bus connection
For 50 and 90 series basic units
ICSI 08 E4 230VAC Digital remote unit
with 8 isolated inputs 230 V a.c.,
230 V a.c. power supply
FPR 331 6401 R0016
ICSO 08 Y1 24VDC Digital remote unit
with 8 transistor outputs 24 V d.c./2 A,
24 V d.c. power supply
FPR 331 1101 R1022
30 series plug-in base For 30 series remote units (with CS31 bus connection)
ECZ Plug-in base for mounting series 30 remote units FPR 370 0001 R0001
