ABB ICMK14F1

Advant Controller AC 31 / Issued: 01.99 3 – 13 Technical specifications
3
ICMK 14 F1 ICMK 14 F1 ICMK 14 N1
24 V d.c. 120/230 V a.c. 24 V d.c.
Integrated outputs
- Number of outputs 6 relays 6 relays 6 transistors
- Isolated outputs (test voltage) 1500 Vrms
1 min
1500 Vrms
1 min
1500 V a.c.
- Output current/channel
Direct voltage 24 V d.c.
Alternating current 24 to 230 V a.c.
2 A
2 A AC-1
0.5 A AC-15
2 A
2 A AC-1
0.5 A AC-15
0.5 A
1 A for
Axx,00 and
Axx,01
- Total load current 6 x 2 A 6 x 2 A 4 x 0.5 A
+ 2 x 1 A
- Output leakage current --
< 200 µA
- Leakage voltage - - 0.2 V max.
500 mA
- Minimum cut-off values 10 mA under
12 V d.c.
10 mA under
12 V d.c.
12 V
- Breaking power under 120 V a.c.
(contact rating code B300) (UL)
2 A 2 A
- Breaking power under 250 V a.c.
(contact rating code B300) (UL)
2 A (1.5 A
acc. to UL)
2 A (1.5 A
acc. to UL)
- Number of groups 2 (2+4) 2 (2+4)
- Switching frequency
for resistive loads
for inductive loads
for lamps
< 1 Hz
< 0.2 Hz
< 0.2 Hz
< 1 Hz
< 0.2 Hz
< 0.2 Hz
< 5 kHz
- Maximum number of switches:
for AC-1
for AC-15
1 million
100.000
1 million
100.000
-
- Short circuit and overload protection external external yes: thermic
- Surge voltage protection external external yes:
by transient
voltage
suppression
- Outputs diagnosis - - Overload and
short circuit
- Cable length:
unshielded
shielded
150 m
500 m
150 m
500 m
150 m
500 m
