ABB ICMK14F1

Advant Controller AC 31 / Issued: 01.99 3 – 17 Technical specifications
3
Digital central extensions specifications continued
Integrated outputs continued XI 16 E1 XO 08 R1 XC 08 L1 XK 08 F1 XO 16N1
- Breaking power under 120 V a.c.
(contact rating code B300) (UL)
-2 A 2 A
- Breaking power under 250 V a.c.
(contact rating code B300) (UL)
- 2 A (1.5 A
according to
UL)
2 A (1.5 A
according to
UL)
- Number of groups 2 (4+4) 1
- Switching rate:
for resistive loads
for inductive loads
for lamps
-
< 1 Hz
< 0.2 Hz
< 0.2 Hz
> 10 kHz < 1 Hz
< 0.2 Hz
< 0.2 Hz
> 10 kHz
- Number of switchin cycles:
for AC-1
for AC-15
- 1 million
100 000
- 1 million
100 000
-
- Short circuit and overload protection - externally yes:
thermic
externally yes:
thermic
- Surge voltage protection - externally yes:
by transient volt
suppresser
externally yes:
by transient volt
suppresser
- Output diagnosis - - overload and
short circuit
- overload and
short circuit
- Cable length:
unshielded
shielded
-
-
150 m
500 m
150 m
500 m
150 m
500 m
150 m
500 m
