Chapter 6 – Communication
NPBA-12 Installation and Start-up Guide 6-3
SAP 60 (Slave_Diag) This SAP gives diagnostic information on the slave station.
Diag_Data (Diagnostic Data)
Type: Octet String - Length: 6 (Standard) + 2 (Extended Diagnosis)
Byte Description
1 Station_Status_1
2 Station_Status_2
3 Station_Status_3
4 Diag.Master_Add
The address of the master that parameterised this slave
5 to 6 Ident_Number (for NPBA-12: 6012h)
Diag.Master_Lock (Set by Master, reset by Slave)
xxxxxxxx
Slave is parameterised by another master
Diag.Prm_Fault (Set by Slave)
Invalid parameter or parameter value
Diag.Invalid_Slave_Response (Set by Master, reset by Slave)
Invalid response by slave
Diag.Not_Supported (Set by Slave)
Service not supported by slave
Diag.Ext_Diag (Set by Slave)
Diagnostic entry present in slave-specific diagnostic area
Diag.Cfg_Fault (Set by Slave)
Received configuration data does not match original configuration data
Diag.Station_Not_Ready (Set by Slave)
Slave not ready for data exchange
Diag.Station_Non_Existent (Set by Master, reset by Slave)
Slave not found
Diag.Deactivated (Set by Master, reset by Slave)
x0xxx1xx
Slave is inactive
Reserved
Diag.Sync_Mode (Set by Slave)
Sync command received by slave
Diag.Freeze_Mode (Set by Slave)
Freeze command received by slave
Diag.WD_On (Set by Slave)
Watchdog on
Diag.Stat_Diag (Set by Slave)
Static diagnosis. Slave (temporarily) unable to provide valid data
Diag.Prm_Req (Set by Slave)
Slave requires re-configuration and re-parameterisation
Always set to 1 by Slave
Diag.Ext_Diag_Overflow (Set by Slave)
Reserved
x0000000
