1 2 3 4 5 6
9 10 11 1287
Remote Reset
TR...
4 3 2 1
T2-T1 S2-S1
PE
MCB
Shunt
trip
L1 L3L2 N
L O A D
POWER SUPPLY
RD3M: 230-400 VAC
RD3M-48: 12-48 VAC/DC
Remote Reset
TR...
4 3 2 1
T2-T1 S2-S1
L O A D
PE
MCB
1 2 3 4 5 6
Undervoltage
release
L1 L3L2 N
POWER SUPPLY
RD3M: 230-400 VAC
RD3M-48: 12-48 VAC/DC
9 10 11 1287
Fault status
Connection to the undervoltage release
23
