ON
7 8 9
FAIL SAFE
OUTPUT Relay
TRIP
10 11 12
7 8 9
10 11 12
FAULTON
OK
RD...
TR...
RD...
RD3M: 230-400 VAC
RD3M-48: 12-48 VAC/DC
7 8 9 10 11 12
Funciones
Fail-safe → integrada en el dispositivo (seguridad positiva). En caso de
ausencia de ausencia de alimentación del dispositivo RD3 los contactos de
salida 10, 11 y 12 conmutarán como en la imagen anexa.
Contactos con dispositivo apagado:
54
