ON
7 8 9
FAIL SAFE
OUTPUT Relay
TRIP
10 11 12
7 8 9
10 11 12
FAULTON
OK
RD...
TR...
RD...
RD3M: 230-400 VAC
RD3M-48: 12-48 VAC/DC
7 8 9 10 11 12
Funzioni
Fail-safe → integrata nel dispositivo (sicurezza positiva). In caso di
mancanza dell’alimentazione del dispositivo RD3 i contatti di output
numerati 10 11 12 commuteranno come da immagine allegata.
Contatti in condizione di dispositivo spento:
6
ABB_76x88mm_RD3M_rev4.indd 6 19/09/11 11:02
