ABB REF 54 Series Technical Reference Manual, General

116
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
Table 9.5.-1 Class 1 data signals
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
Protection functions
AR5FUNC AR sequence successful A *) 128 0 1 1
AR5FUNC AR not in use / AR in use A *) 16 1 1 1,9
AR5FUNC AR interrupted by the signal ARINH A *) 130 0 1 1
AR5FUNC Auto-reclosing sequence P 169 120 0 1 1
AR5FUNC DEF.TRIP alarm P 169 150 0 1 1
AR5FUNC Manual/remote CB opening recognized P 169 160 0 1 1
AR5FUNC AR5FUNC CB operation failed P 169 161 0 1 1
AR5FUNC CB closing inhibited P 169 162 0 1 1
AR5FUNC LOCKOUT P 169 164 1 1 1,9
AR5FUNC Auto-reclose shot 1 P 169 101 0 1 1
AR5FUNC AR shot 1 successful P 169 111 0 1 1
AR5FUNC Auto-reclose shot 2 P 169 102 0 1 1
AR5FUNC AR shot 2 successful P 169 112 0 1 1
AR5FUNC Auto-reclose shot 3 P 169 103 0 1 1
AR5FUNC AR shot 3 successful P 169 113 0 1 1
AR5FUNC Auto-reclose shot 4 P 169 104 0 1 1
AR5FUNC AR shot 4 successful P 169 114 0 1 1
AR5FUNC Auto-reclose shot 5 P 169 105 0 1 1
AR5FUNC AR shot 5 successful P 169 115 0 1 1
AR5FUNC Final trip P 169 121 0 1 1
AR5FUNC Change in CB position B 240 180 0 1 1
CUB1Cap CBFP signal from CUB1Cap A *) 85 0 2 1
CUB1Cap START signal from CUB1Cap dI1 stage P 182 1 1 1 1,9
CUB1Cap TRIP signal from CUB1Cap dI1 stage P 182 2 0 1 1
CUB1Cap ST_ALARM signal from CUB1Cap dI2 stage P 182 3 1 1 1,9
CUB1Cap ALARM signal from CUB1Cap dI2 stage P 182 4 1 1 1,9
CUB3Cap CBFP signal from CUB3Cap A *) 85 0 1 1
CUB3Cap START signal from CUB3Cap stage st1 P 185 1 1 1 1,9
CUB3Cap TRIP signal from CUB3Cap stage st1 P 185 2 0 1 1
CUB3Cap ST_ALARM signal from CUB3Cap stage st2 P 185 3 1 1 1,9
CUB3Cap ALARM signal from CUB3Cap stage st2 P 185 4 1 1 1,9
CUB3LOW CBFP signal from DI> stage A *) 85 0 2 1
CUB3LOW START signal from DI> stage P 173 84 1 1 1,9
CUB3LOW TRIP signal from DI> stage P 173 90 0 1 1
DEF2HIGH CBFP signal from Io>> -> A *) 85 0 2 1
DEF2HIGH START signal from Io>> -> P 163 95 1 1 1,9
DEF2HIGH TRIP signal from Io>> -> P 163 93 0 1 1
DEF2INST CBFP signal from Io>>> -> A *) 85 0 2 1
DEF2INST START signal from Io>>> -> P 163 97 1 1 1,9
DEF2INST TRIP signal from Io>>> -> P 163 99 0 1 1
DEF2LOW CBFP signal from Io> -> A *) 85 0 2 1
DEF2LOW START signal from Io> -> P 163 67 1 1 1,9
DEF2LOW TRIP signal from Io> -> P 163 92 0 1 1
DOC6HIGH CBFP signal from 3I>> -> stage A *) 85 0 2 1
DOC6HIGH START signal from 3I>> -> stage P 164 94 1 1 1,9
DOC6HIGH TRIP signal from 3I>> -> stage P 164 91 0 1 1
DOC6INST CBFP signal from 3I>>> -> stage A *) 85 0 2 1
DOC6INST START signal from 3I>>> -> stage P 164 96 1 1 1,9
