DOC6INST TRIP signal from 3I>>> -> stage P 164 98 0 1 1
DOC6LOW CBFP signal from 3I> -> stage A *) 85 0 2 1
DOC6LOW START signal from 3I> -> stage P 164 84 1 1 1,9
DOC6LOW TRIP signal from 3I> -> stage P 164 90 0 1 1
FLOC Fault detected (float) P 253 127 0 4 1
FLOC Fault alarm P 253 128 0 1 1
FREQ1ST1 START1 signal from f>,f< St1 P 171 84 1 1 1,9
FREQ1ST1 TRIP1 signal from f>,f< St1 P 171 90 0 1 1
FREQ1ST1 START2 signal from f>,f< St1 P 171 94 1 1 1,9
FREQ1ST1 TRIP2 signal from f>,f< St1 P 171 91 0 1 1
FREQ1ST2 START1 signal from f>,f< St2 P 172 84 1 1 1,9
FREQ1ST2 TRIP1 signal from f>,f< St2 P 172 90 0 1 1
FREQ1ST2 START2 signal from f>,f< St2 P 172 94 1 1 1,9
FREQ1ST2 TRIP2 signal from f>,f< St2 P 172 91 0 1 1
FREQ1ST3 START1 signal from f>,f< St3 P 183 84 1 1 1,9
FREQ1ST3 TRIP1 signal from f>,f< St3 P 183 90 0 1 1
FREQ1ST3 START2 signal from f>,f< St3 P 183 94 1 1 1,9
FREQ1ST3 TRIP2 signal from f>,f< St3 P 183 91 0 1 1
FREQ1ST4 START1 signal from f>,f< St4 P 174 84 1 1 1,9
FREQ1ST4 TRIP1 signal from f>,f< St4 P 174 90 0 1 1
FREQ1ST4 START2 signal from f>,f< St4 P 174 94 1 1 1,9
FREQ1ST4 TRIP2 signal from f>,f< St4 P 174 91 0 1 1
FREQ1ST5 START1 signal from f>,f< St5 P 175 84 1 1 1,9
FREQ1ST5 TRIP1 signal from f>,f< St5 P 175 90 0 1 1
FREQ1ST5 START2 signal from f>,f< St5 P 175 94 1 1 1,9
FREQ1ST5 TRIP2 signal from f>,f< St5 P 175 91 0 1 1
FUSEFAIL Fuse failure P 253 83 1 1 1,9
INRUSH3 START signal from 3I2f> P 167 84 1 1 1,9
MotStart START signal from MotStart P 178 84 1 1 1,9
MotStart TRIP signal from MotStart P 178 90 0 1 1
MotStart STALL signal from MotStart P 178 85 0 1 1
NEF1HIGH CBFP signal from Io>> stage A *) 85 0 2 1
NEF1HIGH TRIP signal from Io>> stage A 160 93 0 2 1
NEF1HIGH START signal from Io>> stage P 162 95 1 1 1,9
NEF1INST CBFP signal from Io>>> stage A *) 85 0 2 1
NEF1INST START signal from Io>>> stage P 162 97 1 1 1,9
NEF1INST TRIP signal from Io>>> stage P 162 99 0 1 1
NEF1LOW CBFP signal from Io> stage A *) 85 0 2 1
NEF1LOW START signal from Io> stage A 160 67 1 2 1,9
NEF1LOW TRIP signal from Io> stage A 160 92 0 2 1
NOC3HIGH CBFP signal from 3I>> stage A *) 85 0 2 1
NOC3HIGH TRIP signal from 3I>> stage A 160 91 0 2 1
NOC3HIGH START signal from 3I>> stage P 162 94 1 1 1,9
NOC3INST CBFP signal from 3I>>> stage A *) 85 0 2 1
NOC3INST START signal from 3I>>> stage P 162 96 1 1 1,9
NOC3INST TRIP signal from 3I>>> stage P 162 98 0 1 1
MotStart START signal from MotStart P 178 84 1 1 1,9
MotStart TRIP signal from MotStart P 178 90 0 1 1
MotStart STALL signal from MotStart P 178 85 0 1 1
NEF1HIGH CBFP signal from Io>> stage A *) 85 0 2 1
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
