118
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
NOC3LOW CBFP signal from 3I> stage A *) 85 0 2 1
NOC3LOW START signal from 3I> stage A 160 84 1 2 1,9
NOC3LOW TRIP signal from 3I> stage A 160 90 0 2 1
OL3Cap CBFP signal from OL3Cap stage A *) 85 0 2 1
OL3Cap START signal from OL3Cap stage Ib> P 181 1 1 1 1,9
OL3Cap TRIP signal from OL3Cap stage P 181 2 0 1 1
OL3Cap START signal from OL3Cap stage Ia> P 181 3 1 1 1,9
OL3Cap ALARM signal from OL3Cap stage P 181 4 1 1 1,9
OL3Cap START signal from OL3Cap stage I< P 181 5 1 1 1,9
OL3Cap TRIP signal from OL3Cap stage I< P 181 6 0 1 1
OL3Cap Reconnection inhibit signal of OL3Cap stage P 181 7 1 1 1,9
OV3HIGH START signal from 3U>> stage P 165 94 1 1 1,9
OV3HIGH TRIP signal from 3U>> stage P 165 91 0 1 1
OV3LOW START signal from 3U> stage P 165 84 1 1 1,9
OV3LOW TRIP signal from 3U> stage P 165 90 0 1 1
PSV3St1 PSV3St1 START U2> P 179 1 1 1 1,9
PSV3St1 PSV3St1 START U1< P 179 2 1 1 1,9
PSV3St1 PSV3St1 START U1> P 179 3 1 1 1,9
PSV3St1 PSV3St1 TRIP U2> P 179 4 0 1 1
PSV3St1 PSV3St1 TRIP U1< P 179 5 0 1 1
PSV3St1 PSV3St1 TRIP U1> P 179 6 0 1 1
PSV3St2 PSV3St2 START U2> P 180 1 1 1 1,9
PSV3St2 PSV3St2 START U1< P 180 2 1 1 1,9
PSV3St2 PSV3St2 START U1> P 180 3 1 1 1,9
PSV3St2 PSV3St2 TRIP U2> P 180 4 0 1 1
PSV3St2 PSV3St2 TRIP U1< P 180 5 0 1 1
PSV3St2 PSV3St2 TRIP U1> P 180 6 0 1 1
ROV1HIGH START signal from Uo>> stage P 170 94 1 1 1,9
ROV1HIGH TRIP signal from Uo>> stage P 170 91 0 1 1
ROV1INST START signal from Uo>>> stage P 170 96 1 1 1,9
ROV1INST TRIP signal from Uo>>> stage P 170 98 0 1 1
ROV1LOW START signal from Uo> stage P 170 84 1 1 1,9
ROV1LOW TRIP signal from Uo> stage P 170 90 0 1 1
SCVCSt1 SC Due P 218 1 1 1 1,9
SCVCSt1 SC Ok P 218 2 1 1 1,9
SCVCSt1 Alarm not passed P 218 3 1 1 1,9
SCVCSt2 SC Due P 219 1 1 1 1,9
SCVCSt2 SC Ok P 219 2 1 1 1,9
SCVCSt2 Alarm not passed P 219 3 1 1 1,9
TOL3CAB CBFP signal from TOL3Cab A *) 85 0 2 1
TOL3CAB START signal from TOL3Cab P 168 84 1 1 1,9
TOL3CAB TRIP signal from TOL3Cab P 168 90 0 1 1
TOL3CAB Current alarm from TOL3Cab P 168 91 0 1 1
TOL3Dev CBFP signal from TOL3Dev A *) 85 0 1 1
TOL3Dev START signal from TOL3Dev P 184 84 1 1 1,9
TOL3Dev TRIP signal from TOL3Dev P 184 90 0 1 1
UV3HIGH START signal from 3U<< stage P 166 94 1 1 1,9
UV3HIGH TRIP signal from 3U<< stage P 166 91 0 1 1
UV3LOW START signal from 3U< stage P 166 84 1 1 1,9
UV3LOW TRIP signal from 3U< stage P 166 90 0 1 1
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
