ABB REF 54 Series Technical Reference Manual, General

1MRS750527-MUM
REF 54_
119
Feeder Terminal
Technical Reference Manual, General
Control functions
CO3DC1 3-state sw. 1 position OC P 253 17 1 1 1,9
CO3DC1 3-state sw. 1 command sequence P 253 9 0 1 1
CO3DC1 3-state sw. 1 open output P 253 10 0 1 1
CO3DC1 3-state sw. 1 close output P 253 11 0 1 1
CO3DC1 3-state sw. 1 opening time P 253 12 0 1 1
CO3DC1 3-state sw. 1 closing time P 253 13 0 1 1
CO3DC1 3-state sw. 1 command status P 253 14 0 1 1
CO3DC1 3-state sw. 1 earthing time P 253 15 0 1 1
CO3DC1 3-state sw. 1 freeing time P 253 16 0 1 1
CO3DC1 3-state sw. 1 position FE P 253 18 1 1 1,9
CO3DC2 3-state sw. 2 position OC P 253 19 1 1 1,9
CO3DC2 3-state sw. 2 command sequence P 253 20 0 1 1
CO3DC2 3-state sw. 2 open output P 253 21 0 1 1
CO3DC2 3-state sw. 2 close output P 253 22 0 1 1
CO3DC2 3-state sw. 2 opening time P 253 23 0 1 1
CO3DC2 3-state sw. 2 closing time P 253 24 0 1 1
CO3DC2 3-state sw. 2 command status P 253 25 0 1 1
CO3DC2 3-state sw. 2 earthing time P 253 26 0 1 1
CO3DC2 3-state sw. 2 freeing time P 253 27 0 1 1
CO3DC2 3-state sw. 2 position FE P 253 28 1 1 1,9
COCB1 Breaker 1 position B 240 160 1 1 1,9
COCB1 Breaker 1 command sequence P 242 201 0 1 1
COCB1 Breaker 1 open output P 242 202 0 1 1
COCB1 Breaker 1 close output P 242 203 0 1 1
COCB1 Breaker 1 opening time P 242 204 0 1 1
COCB1 Breaker 1 closing time P 242 205 0 1 1
COCB1 Breaker 1 command status P 242 206 0 1 1
COCB2 Breaker 2 position P 242 207 1 1 1,9
COCB2 Breaker 2 open output P 243 201 0 1 1
COCB2 Breaker 2 close output P 243 202 0 1 1
COCB2 Breaker 2 opening time P 243 203 0 1 1
COCB2 Breaker 2 closing time P 243 204 0 1 1
COCB2 Breaker 2 command status P 243 205 0 1 1
COCB2 Breaker 2 command sequence P 253 29 0 1 1
COCBDIR Breaker open command P 253 30 0 1 1
CODC1 Disconnector 1 position P 243 206 1 1 1,9
CODC1 Disconnector 1 command seq. P 253 31 0 1 1
CODC1 Disconnector 1 open output P 253 32 0 1 1
CODC1 Disconnector 1 close output P 253 33 0 1 1
CODC1 Disconnector 1 opening time P 253 34 0 1 1
CODC1 Disconnector 1 closing time P 253 35 0 1 1
CODC1 Disconnector 1 command status P 253 36 0 1 1
CODC2 Disconnector 2 position P 253 37 1 1 1,9
CODC2 Disconnector 2 command seq. P 253 38 0 1 1
CODC2 Disconnector 2 open output P 253 39 0 1 1
CODC2 Disconnector 2 close output P 253 40 0 1 1
CODC2 Disconnector 2 opening time P 253 41 0 1 1
CODC2 Disconnector 2 closing time P 253 42 0 1 1
CODC2 Disconnector 2 command status P 253 43 0 1 1
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
