ABB REF 54 Series Technical Reference Manual, General

120
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
CODC3 Disconnector 3 position P 253 44 1 1 1,9
CODC3 Disconnector 3 command seq. P 253 45 0 1 1
CODC3 Disconnector 3 open output P 253 46 0 1 1
CODC3 Disconnector 3 close output P 253 47 0 1 1
CODC3 Disconnector 3 opening time P 253 48 0 1 1
CODC3 Disconnector 3 closing time P 253 49 0 1 1
CODC3 Disconnector 3 command status P 253 50 0 1 1
CODC4 Disconnector 4 position P 253 51 1 1 1,9
CODC4 Disconnector 4 command seq. P 253 52 0 1 1
CODC4 Disconnector 4 open output P 253 53 0 1 1
CODC4 Disconnector 4 close output P 253 54 0 1 1
CODC4 Disconnector 4 opening time P 253 55 0 1 1
CODC4 Disconnector 4 closing time P 253 56 0 1 1
CODC4 Disconnector 4 command status P 253 57 0 1 1
CODC5 Disconnector 5 position P 253 58 1 1 1,9
CODC5 Disconnector 5 command seq. P 253 59 0 1 1
CODC5 Disconnector 5 open output P 253 60 0 1 1
CODC5 Disconnector 5 close output P 253 61 0 1 1
CODC5 Disconnector 5 opening time P 253 62 0 1 1
CODC5 Disconnector 5 closing time P 253 63 0 1 1
CODC5 Disconnector 5 command status P 253 64 0 1 1
COIND1 Indication 1 position B 240 161 1 1 1,9
COIND2 Indication 2 position B 240 164 1 1 1,9
COIND3 Indication 3 position P 240 165 1 1 1,9
COIND4 Indication 4 position P 253 65 1 1 1,9
COIND5 Indication 5 position P 253 66 1 1 1,9
COIND6 Indication 6 position P 253 67 1 1 1,9
COIND7 Indication 7 position P 253 68 1 1 1,9
COIND8 Indication 8 position P 253 69 1 1 1,9
COLOCAT Logic position setting P 253 100 0 1 1
COPFC Control oper. failed, COPFC P 253 78 1 1 1,9
COPFC Q not within limits, COPFC P 253 70 1 1 1,9
COPFC Pumping situation alarm, COPFC P 253 71 1 1 1,9
COPFC Not discharged yet, COPFC P 253 72 0 1 1
COPFC Overvoltage inhibition, COPFC P 253 75 0 1 1
COPFC DISCONNECT signal of COPFC P 253 77 1 1 1,9
COSW1 On/off object 1 position P 253 79 1 1 1,9
COSW2 On/off object 2 position P 253 80 1 1 1,9
COSW3 On/off object 3 position P 253 81 1 1 1,9
COSW4 On/off object 4 position P 253 82 1 1 1,9
MMIALAR1 Alarm 1 status P 253 88 1 1 1,9
MMIALAR2 Alarm 2 status P 253 89 1 1 1,9
MMIALAR3 Alarm 3 status P 253 90 1 1 1,9
MMIALAR4 Alarm 4 status P 253 91 1 1 1,9
MMIALAR5 Alarm 5 status P 253 92 1 1 1,9
MMIALAR6 Alarm 6 status P 253 93 1 1 1,9
MMIALAR7 Alarm 7 status P 253 94 1 1 1,9
MMIALAR8 Alarm 8 status P 253 95 1 1 1,9
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
