ABB REF 54 Series Technical Reference Manual, General

122
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
EVENT230 Customer event 50-51 P 252 26 0 1 1
EVENT230 Customer event 52-53 P 252 27 0 1 1
EVENT230 Customer event 54-55 P 252 28 0 1 1
EVENT230 Customer event 56-57 P 252 29 0 1 1
EVENT230 Customer event 58-59 P 252 30 0 1 1
EVENT230 Customer event 60-61 P 252 31 0 1 1
EVENT230 Customer event 62-63 P 252 32 0 1 1
LocalMMI Password changed P 252 34 0 1 1
LocalMMI Setting done P 252 33 0 1 1
Measurement functions
MEAI1 High warning P 210 11 0 1 1
MEAI1 High alarm P 210 21 0 1 1
MEAI1 Low warning P 210 111 0 1 1
MEAI1 Low alarm P 210 121 0 1 1
MEAI2 High warning P 211 11 0 1 1
MEAI2 High alarm P 211 21 0 1 1
MEAI2 Low warning P 211 111 0 1 1
MEAI2 Low alarm P 211 121 0 1 1
MEAI3 High warning P 212 11 0 1 1
MEAI3 High alarm P 212 21 0 1 1
MEAI3 Low warning P 212 111 0 1 1
MEAI3 Low alarm P 212 121 0 1 1
MEAI4 High warning P 213 11 0 1 1
MEAI4 High alarm P 213 21 0 1 1
MEAI4 Low warning P 213 111 0 1 1
MEAI4 Low alarm P 213 121 0 1 1
MEAI5 High warning P 214 11 0 1 1
MEAI5 High alarm P 214 21 0 1 1
MEAI5 Low warning P 214 111 0 1 1
MEAI5 Low alarm P 214 121 0 1 1
MEAI6 High warning P 215 11 0 1 1
MEAI6 High alarm P 215 21 0 1 1
MEAI6 Low warning P 215 111 0 1 1
MEAI6 Low alarm P 215 121 0 1 1
MEAI7 High warning P 216 11 0 1 1
MEAI7 High alarm P 216 21 0 1 1
MEAI7 Low warning P 216 111 0 1 1
MEAI7 Low alarm P 216 121 0 1 1
MEAI8 High warning P 217 11 0 1 1
MEAI8 High alarm P 217 21 0 1 1
MEAI8 Low warning P 217 111 0 1 1
MEAI8 Low alarm P 217 121 0 1 1
MEDREC16 Recorder memory is full P 195 50 0 1 1
MEDREC16 Recorder triggered P 195 51 0 1 1
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
