ABB REF 54 Series Technical Reference Manual, General

1MRS750527-MUM
REF 54_
123
Feeder Terminal
Technical Reference Manual, General
Command
Explanations to Table 9.5.-2:
General functions
CH000 IRF error P 253 1 0 1 1
CH001 Test mode P 253 5 0 1 1
CH002
1)
Recent control position P 253 6 1 1 1,9
INDRESET Indications P 253 85 0 1 1
INDRESET Indications, latched P 253 86 0 1 1
INDRESET Indicat., latched, registered P 253 87 0 1 1
1)
0 = disable, 1 = local, 2 = remote
St
Status
A According to the IEC 60870-5-103 standard
B According to “Digitale Stationsleittechnik - Ergänzende Empfehlungen zur
Anwendung in Verteilnetzstationen”
P Private definition
Ftyp
Function type
Note: If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the “Function type” parameter.
InfNum
Information element number
COT cmd
Cause of transmission values in command direction
20 General command
COT resp
Cause of transmission values in response direction
20 Positive acknowledgement
21 Negative acknowledgement
Table 9.5.-2 Commands
Commands St Ftyp
Inf
Num
Typ
COT
cmd
COT
resp
COCB1 Circuit breaker B 240 160 20 20 20,21
COCB2 Circuit breaker P 242 207 20 20 20,21
CODC1 Disconnector P 243 206 20 20 20,21
CODC2 Disconnector P 253 37 20 20 20,21
CODC3 Disconnector P 253 44 20 20 20,21
CODC4 Disconnector P 253 51 20 20 20,21
CODC5 Disconnector P 253 58 20 20 20,21
CO3DC1 Disconnector P 253 17 20 20 20,21
CO3DC1 Disconnector Earth P 253 18 20 20 20,21
CO3DC2 Disconnector P 253 19 20 20 20,21
CO3DC2 Disconnector Earth P 253 28 20 20 20,21
COSW1 On / Off switch 1 P 253 79 20 20 20,21
COSW2 On / Off switch 2 P 253 80 20 20 20,21
COSW3 On / Off switch 3 P 253 81 20 20 20,21
COSW4 On / Off switch 4 P 253 82 20 20 20,21
Table 9.5.-1 Class 1 data signals (Continued)
Function block
name
Event St Ftyp
Inf
Num
GI Typ COT
