Feeder Terminal
Technical Reference Manual, General
REF 54_
Class 2 measurand sets
Explanations to Table 9.5.-3:
*) According to the device function type.
**) Selected by RTD data frame parameter.
SetNo
Class 2 measurand set No (1...11). The measurand set can be selected by
setting the parameter “Measurement frame type”.
St
A According to the IEC 60870-5-103 standard
P Private definition
FuncType/
InfoNum
Class 2 Frame identification
Note: If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the “Function type” parameter.
Num data
The number of the data values in the class 2 message data part
Typ
Meas type 3 or 9 (when the definition is private, meas type 9 is used)
Data
Measurement data in class 2 message data part:
Not available: -
Table 9.5.-3 Recommended Class 2 measurand sets
Set No St Functyp
Info
Num
Num
data
Typ Data
1 Meas I: 144 A *) 144 1 3 IL2
2 Meas I: 145 A *) 145 2 3 IL2, U12
3 Meas I: 146 A *) 146 4 3 IL1, U12, P, Q
4 Meas I: 147 A *) 147 2 3 Io, Uo
5 Meas II: 148 A *) 148 9 9 IL1, IL2, IL3, U1, U2, U3, P, Q, f
6 Meas II: ABB1 P 134 137 16 9 IL1, IL2, IL3, Io, -, -, -, U12, U23, U31, P,
Q, f, -, -, PF
7 Meas II: ABB2 P 134 137 16 9 IL1, IL2, IL3, Io, U1, U2, U3, -, -, -, P, Q,
f, -, -, PF
8 Meas II: ABB3 P 135 137 12 9 IL1, IL2, IL3, U1, U2, U3, Io, Uo, P, Q,
PF, f
9 Meas II: ABB4 P 135 138 12 9 IL1, IL2, IL3, U12, U23, U31, Io, Uo, P,
Q, PF, f
10 Meas II: ABB5 P 135 139 4 9 IL1, IL2, IL3, Io
11 Meas II: ABB6 P 135 140 5 9 IL1, IL2, IL3, Io, Uo
12 Meas II: ABB7 P 136 141 14 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U1, I0,
U0, I0B, P, Q, PF, f
13 Meas II: ABB8 P 136 142 14 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U12, I0,
I0B, U0, P, Q, PF, f
14 Meas II: ABB9 P 136 143 15 9 IL1, IL2, IL3, U12, U23, U31, U1b, I0,
I0B, U0, U0B, P, Q, PF, f
15 Meas II: ABB10 P 136 144 15 9 IL1, IL2, IL3, U1, U2, U3, U12B, I0, IOB,
U0, U0B, P, Q, PF, f
16 Meas II: ABB11 P 136 145 20 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U1, U2,
U3, U1B, U2B, U3B, I0, I0B, U0, U0B, P,
Q, PF, f
17 Meas II: ABB12 P 136 146 20 9 IL1, IL2, IL3, IL1B, IL2B, IL3B, U12,
U23, U31, U12B, U23B, U31B, Io, IoB,
Uo, UoB, P, Q, PF, f
RTD frame if card installed and frame selected
RTD**
)
P 136 147 8 9 RTD1, RTD2, RTD3, RTD4, RTD5,
RTD6, RTD7, RTD8
