ABB REF 54 Series Technical Reference Manual

112
1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
&RQGLWLRQPRQLWRULQJIXQFWLRQV
CMBWEAR1 Breaker 1 electric wear alarm P 194 10 0 1 1
CMBWEAR2 Breaker 2 electric wear alarm P 194 11 0 1 1
CMCU3 Current input circuit alarm A *) 32 1 1 1,9
CMGAS1 Low gas density alarm P 238 1 1 1 1,9
CMGAS1 Low gas density warning P 238 2 1 1 1,9
CMGAS3 Low gas density alarm P 238 3 1 1 1,9
CMSCHED Scheduled maintenance alarm P 238 4 0 1 1
CMSPRC1 Spring 1 charging motor P 238 7 0 1 1
CMSPRC1 Spring 1 max charging alarm P 238 5 1 1 1,9
CMSPRC1 Spring 1 min charging alarm P 238 6 1 1 1,9
CMTCS1 Trip circuit supervision 1 alarm A *) 36 1 1 1,9
CMTCS2 Trip circuit superv. 2 alarm P 238 10 1 1 1,9
CMTIME1 Accumulated time 1 alarm P 238 12 1 1 1,9
CMTIME1 Accumulated time 1 measurement P 238 11 1 1 1,9
CMTIME2 Accumulated time 1 alarm P 238 13 1 1 1,9
CMTIME2 Accumulated time 1 measurement P 238 14 1 1 1,9
CMTRAV1 Breaker 1 open travel alarm P 238 16 1 1 1,9
CMTRAV1 Breaker 1 close travel alarm P 238 15 1 1 1,9
CMVO3 Input voltage circuit alarm A *) 33 1 1 1,9
3RZHUTXDOLW\IXQFWLRQV
PQCU3H Current harmonic limit P 204 20 0 1 1
PQVO3H Voltage waveform distortion measurement P 205 20 0 1 1
&RPPXQLFDWLRQIXQFWLRQV
EVENT230 Customer event 0-1 P 252 1 0 1 1
EVENT230 Customer event 2-3 P 252 2 0 1 1
EVENT230 Customer event 4-5 P 252 3 0 1 1
EVENT230 Customer event 6-7 P 252 4 0 1 1
EVENT230 Customer event 8-9 P 252 5 0 1 1
EVENT230 Customer event 10 -11 P 252 6 0 1 1
EVENT230 Customer event 12-13 P 252 7 0 1 1
EVENT230 Customer event 14-15 P 252 8 0 1 1
EVENT230 Customer event 16-17 P 252 9 0 1 1
EVENT230 Customer event 18-19 P 252 10 0 1 1
EVENT230 Customer event 20-21 P 252 11 0 1 1
EVENT230 customer event 22-23 P 252 12 0 1 1
EVENT230 Customer event 24-25 P 252 13 0 1 1
EVENT230 Customer event 26-27 P 252 14 0 1 1
EVENT230 Customer event 28-29 P 252 15 0 1 1
EVENT230 Customer event 30-31 P 252 16 0 1 1
EVENT230 Customer event 32-33 P 252 17 0 1 1
EVENT230 Customer event 34-35 P 252 18 0 1 1
EVENT230 Customer event 36-37 P 252 19 0 1 1
EVENT230 Customer event 38-39 P 252 20 0 1 1
EVENT230 Customer event 40-41 P 252 21 0 1 1
EVENT230 Customer event 42-43 P 252 22 0 1 1
EVENT230 Customer event 44-45 P 252 23 0 1 1
EVENT230 Customer event 46-47 P 252 24 0 1 1
EVENT230 Customer event 48-49 P 252 25 0 1 1
EVENT230 Customer event 50-51 P 252 26 0 1 1
*)
The signal type Ftyp corresponds with the unit function type.
7DEOH &ODVVGDWDVLJQDOV
)XQFWLRQEORFN
QDPH
(YHQW 6W )W\S
,QI
1XP
*, 7\S &27
