1MRS750527-MUM
)HHGHU7HUPLQDO
Technical Reference Manual, General
5()B
89
The display language combination (see table below) is identified by a three-digit
suffix in the software number labeled on the front panel of the feeder terminal, e.g.
Software No: 1MRS110028-0__.
The REF 541, REF 543 and REF 545 feeder terminals differ from each other as to
the number of digital inputs and outputs as follows.
+DUGZDUHYHUVLRQVRI5()5()DQG5()
For the number of digital inputs and outputs of REF 54_ feeder terminals, refer to
section “Order number” above. The number of matching transformers, sensor inputs
and analogue inputs and outputs, and the auxiliary voltage range vary between the
different hardware versions of REF 54_. Moreover, REF 541 and REF 543 can be
supplied with an RTD/analogue module. For more detailed information about the
hardware of REF 54_, refer to section “Hardware versions” on page 9.
6RIWZDUHFRQILJXUDWLRQ
Each REF 54_ feeder terminal allows different software configurations based on
separate functions (refer to section “Functions of the feeder terminal” on page 17).
Functions included in the selected functionality level (refer to section “Ordering
Information” on page 88) can be activated within the scope of the I/O connections
and considering the total CPU load of the functions.
6XIIL[ /DQJXDJHFRPELQDWLRQ
001 English - German
002 English - Swedish
003 English - Finnish
007 English - Portuguese
008 English - Polish
010 English - Spanish
1XPEHURILQSXWVRXWSXWV 5() 5() 5()
Digital inputs 15 25 34
Trip circuit supervision inputs 2 2 2
Power outputs (NO single-pole) 0 2 3
Power outputs (NO double-pole) 5 9 11
Signal outputs (NO) 2 2 4
Signal outputs (NO/NC) 5 5 8
Self-supervision outputs 1 1 1
