Table 2. Supported functions, continued
Function IEC 61850 A C D
Current circuit supervision CCSPVC 1
Fuse failure supervision SEQSPVC 1 1 1
Runtime counter for machines and devices MDSOPT 1 1 1
Measurement
Disturbance recorder RDRE 1 1 1
Load profile record LDPRLRC 1 1 1
Fault record FLTRFRC 1 1 1
Three-phase current measurement CMMXU 1 1 2
Sequence current measurement CSMSQI 1 1 1
Residual current measurement RESCMMXU 1 1 1
Three-phase voltage measurement VMMXU 2 1 2
Residual voltage measurement RESVMMXU 1 2 1
Sequence voltage measurement VSMSQI 1 1 1
Three-phase power and energy measurement PEMMXU 1 1 1
RTD/mA measurement XRGGIO130 (1) (1) (1)
Frequency measurement FMMXU 1 1 1
IEC 61850-9-2 LE sampled value sending
5)6)
SMVSENDER (1) (1) (1)
IEC 61850-9-2 LE sampled value receiving (voltage sharing)
5)6)
SMVRCV (1) (1) (1)
Other
Minimum pulse timer (2 pcs) TPGAPC 4 4 4
Minimum pulse timer (2 pcs, second resolution) TPSGAPC 1 1 1
Minimum pulse timer (2 pcs, minute resolution) TPMGAPC 1 1 1
Pulse timer (8 pcs) PTGAPC 2 2 2
Time delay off (8 pcs) TOFGAPC 4 4 4
Time delay on (8 pcs) TONGAPC 4 4 4
Set-reset (8 pcs) SRGAPC 4 4 4
Move (8 pcs) MVGAPC 2 2 2
Generic control point (16 pcs) SPCGAPC 2 2 2
Analog value scaling (4 pcs) SCA4GAPC 4 4 4
Integer value move (4 pcs) MVI4GAPC 1 1 1
1, 2, ... = Number of included instances. The instances of a protection function represent the number of identical protection function blocks available in the standard
configuration.
() = optional
TR = The function block is to be used on the terminal side in the application.
1) "Io measured" is always used.
2) "Io calculated" is always used.
3) Master trip is included and connected to the corresponding HSO in the configuration only when the BIO0007 module is used. If additionally the ARC option is selected, ARCSARC is
connected in the configuration to the corresponding master trip input.
4) Power quality option includes current total demand distortion, voltage total harmonic distortion, voltage variation and voltage unbalance.
5) Available only with IEC 61850-9-2
6) Available only with COM0031...0037
