Table 2-6: RECLOSING SETTINGS WITH RANGES (Sheet 1 of 4)
Setting
Function
Display
RCP
Display
Value
Displayed
Factory
Default
* Synchronism Functions Enable Sync Set ? Sync Set No / Yes No
* “LIVE” Voltage Threshold V Max V Max 30 -70 Step 1 Volt
50-120 Step 1 Volt (120 Volt option)
53 Volts
90 Volts
* “Dead” Voltage Threshold V Min V Min 0 -30 Step 1 Volt
0 - 50 Step 1 Volt (120 Volt option)
13 Volts
22 Volts
* Maximum Angle for Synchro-
nism
Sync Angle Sync Ang 0 - 60 Step 1
o
(degrees) 20
o
Synchronism Voltage Reference Sync Volt Sync Volt Line Side/Bus Side Line Side
* Present Synchro / HLDB /HBDL
Minimal Condition Duration
Sync Time Sync Time 0.01 - 0.99 Step 0.01 sec
1.0 - 9.9 Step 0.1 sec
10 - 20 Step 1 sec
2.0 sec
Number of Reclosure Reclosures # Reclose 0 - 4 recl 4 recl
Reclosure 1 parameters:
- Reclose 1 Initiation Method Recl 1
(RECI 1)
Recl n Init 52b only /
3RI only /
52b and 3RI /
52b or 3RI
52b Only
- Reclose Block
(“Recl1” must be set to one of
the setting choices that includes
3RI to view this setting)
Recl1 RB Recl n RB No / Yes No
- Reclose 1 Dead Time Recl1 Time Recl n Time 0.01 - 0.99 Step 0.01 sec
1.0 - 9.9 Step 0.1 sec
10 - 250 Step 1 sec
0.50 sec
* - Reclose 1 on HLDB Recl1 HLDB Recl n HLDB No / Yes No
* - Reclose 1 on HBDL Recl1 HBDL Recl n HBDL No / Yes No
* - Reclose 1 on Synchronism Recl1 Sync Recl n Sync No / Yes No
* - 1 Max Wait Time for a HBDL,
HLDB or Synchronism condition.
(Recl1 HLDB, HBDL or Sync
must be “yes” to view this set-
ting)
Recl1 Wait Recl n Wait 0 - 99 Step 1 sec
100 - 990 Step 10 sec
No time Limit
(Infinite Wait Time)
60 sec
Reclosure 2 parameters:
- Reclosure 2 Initiation Method Recl 2
(RECI 2)
Recl n Init 52b only /
3RI only /
52b and 3RI /
52b or 3RI
52b Only
- Reclose 2 Block
(“Recl2” must be set to one of
the setting choices that includes
3RI to view this setting)
Recl2 RB Recl n RB No / Yes No
* Settings available only with synchronism check option and when Sync Set? = Yes
