- Reclose 2 Dead Time Recl2 Time Recl n Time 0.01 - 0.99 Step 0.01 sec
1.0 - 99 Step 0.1 sec
10 - 250 Step 1 sec
3.0 sec
* - Reclose 2 on HLDB Recl2 HLDB Recl n HLDB No / Yes No
* - Reclose 2 on HBDL Recl2 HBDL Recl n HBDL No / Yes No
* - Reclose 2 on Synchronism Recl2 Sync Recl n Sync No / Yes No
* - 2 Max Wait Time for a HLDB,
HBDL or Synchronism condition.
(Recl2 HLDB, HBDL or Sync
must be “yes” to view this set-
ting)
Recl2 Wait Recl n Wait 0 - 99 Step 1 sec
100 - 990 Step 10 sec
No time Limit
(Infinite Time)
60 sec
Reclosure 3 parameters:
- Reclosure 3 Initiation Method
Recl 3
(RECI 3)
Recl n Init
52b only /
3RI only /
52b and 3RI /
52b or 3RI
52b Only
- Reclose 3 Block
(“Recl3” must be set to one of
the setting choices that includes
3RI to view this setting)
Recl3 RB Recl n RB No / Yes No
- Reclose Dead Time Recl3 Time Recl n Time 0.01 - 0.99 Step 0.01 sec
1.0 - 9.9 Step 0.1 sec
10 - 250 Step 1 sec
10 sec
* - Reclose 3 on HLDB Recl3 HLDB Recl n HLDB No / Yes No
* - Reclose 3 on HBDL Recl3 HBDL Recl n HBDL No / Yes No
* - Reclose 3 on Synchronism Recl3 Sync Recl n Sync No / Yes No
* - 3 Max Wait Time for a HLDB,
HBDL or Synchronism condition.
(Recl3 HLDB, HBDL or Sync
must be “yes” to view this set-
ting)
Recl3 Wait Recl n Wait 0 - 99 Step 1 sec
100 - 990 Step 10 sec
No time Limit (Infinite Time)
60 sec
Reclosure 4 parameters:
- Reclosure 4 Initiation Method
Recl 4
(RECI 4)
Recl n Init
52b only /
3RI only /
52b and 3RI /
52b or 3RI
52b Only
- Reclose 4 Block
(“Recl4” must be set to one of
the setting choices that includes
3RI to view this setting)
Recl4 RB Recl n RB No / Yes No
- Reclose 4 Dead Time Recl4 Time Recl n Time 0.01 - 0.99 Step 0.01 sec
1.0 - 9.9 Step 0.1 sec
10 - 250 Step 1 sec
30 sec
* - Reclose 4 on HLDB Recl4 HLDB Recl n HLDB No / Yes No
Table 2-6: RECLOSING SETTINGS WITH RANGES (Sheet 2 of 4)
Setting
Function
Display
RCP
Display
Value
Displayed
Factory
Default
* Settings available only with synchronism check option and when Sync Set? = Yes
