3.1.2.1 I/O modules
M11880-16 v4
To read binary inputs, the SPA-addresses for the outputs of the I/O-module function block are
used, that is, the addresses for BI1 – BI16. For SPA addresses, refer to section Related
documents in Product Guide.
M11880-35 v1
3.1.2.2 Single command, 16 signals
M11880-51 v5
The IEDs can be provided with a function to receive signals either from a substation
automation system or from the local HMI. That receiving function block has 16 outputs that
can be used, for example, to control high voltage apparatuses in switchyards. For local control
functions, the local HMI can also be used.
The single command, 16 signals function consists of four function blocks: SINGLECMD:1 to
SINGLECMD:4 for 16 binary output signals each.
The signals can be individually controlled from the operator station, remote-control gateway,
or from the local HMI on the IED. For Single command, 3 signals function block, SINGLECMD:1
to SINGLECMD:3, the address is for the first output. The other outputs follow consecutively
after the first one. For example, output 7 on the SINGLECMD:2 function block has the 5O533
address.
The SPA addresses for Single command, 16 signals functions SINGLECMD:1 to SINGLECMD:4
are found in table
2.
Table 2: SPA addresses for SINGLECMD function
Function block SPA address CMD Input SPA address CMD output
SINGLECMD1-Cmd1 4-S-4639 5-O-511
SINGLECMD1-Cmd2 4-S-4640 5-O-512
SINGLECMD1-Cmd3 4-S-4641 5-O-513
SINGLECMD1-Cmd4 4-S-4642 5-O-514
SINGLECMD1-Cmd5 4-S-4643 5-O-515
SINGLECMD1-Cmd6 4-S-4644 5-O-516
SINGLECMD1-Cmd7 4-S-4645 5-O-517
SINGLECMD1-Cmd8 4-S-4646 5-O-518
SINGLECMD1-Cmd9 4-S-4647 5-O-519
SINGLECMD1-Cmd10 4-S-4648 5-O-520
SINGLECMD1-Cmd11 4-S-4649 5-O-521
SINGLECMD1-Cmd12 4-S-4650 5-O-522
SINGLECMD1-Cmdt13 4-S-4651 5-O-523
SINGLECMD1-Cmd14 4-S-4652 5-O-524
SINGLECMD1-Cmd15 4-S-4653 5-O-525
SINGLECMD1-Cmd16 4-S-4654 5-O-526
SINGLECMD2-Cmd1 4-S-4672 5-O-527
SINGLECMD2-Cmd2 4-S-4673 5-O-528
SINGLECMD2-Cmdt3 4-S-4674 5-O-529
SINGLECMD2-Cmd4 4-S-4675 5-O-530
SINGLECMD2-Cmd5 4-S-4676 5-O-531
SINGLECMD2-Cmd6 4-S-4677 5-O-532
Table continues on next page
Section 3 1MRK 511 396-UEN E
SPA operation principle
12 SPA, 670 series
Communication protocol manual
© Copyright 2017 ABB. All rights reserved
