IEC 61850 name AFL-Common SA name Description DPI value FUN INF InUse ASDU GI Coding
Phase overcurrent protection (2 stages)
LD0.PHIPTOC1.Str.phsA - Instanteous stage Start[.phsA] 10=Inst.Stage phsA start 162 34 0 2 1 1
LD0.PHIPTOC1.Str.phsB - Instanteous stage Start[.phsB] 10=Inst.Stage phsB start 162 35 0 2 1 1
LD0.PHIPTOC1.Str.phsC - Instanteous stage Start[.phsC] 10=Inst.Stage phsC start 162 36 0 2 1 1
LD0.PHLPTOC1.Str.phsA - Low stage Start[.phsA] 10=Low Stage phsA start 162 64 0 2 1 1
LD0.PHLPTOC1.Str.phsB - Low stage Start[.phsB] 10=Low Stage phsB start 162 65 0 2 1 1
LD0.PHLPTOC1.Str.phsC - Low stage Start[.phsC] 10=Low Stage phsC start 162 66 0 2 1 1
LD0.PHLPTOC1.Str.general PHLPTOC1.START Low stage Start[.general] 10=Low Stage start 162 84 1 2 1 1
LD0.PHLPTOC1.Op.general PHLPTOC1.OPERATE Low stage Operate[.general] 10=Low Stage operate 162 90 1 2 0 1
LD0.PHIPTOC1.Str.general PHIPTOC1.START Instanteous stage Start[.general] 10=Inst Stage start 162 97 1 2 1 1
LD0.PHIPTOC1.Op.general PHIPTOC1.OPERATE
Instanteous stage
Operate[.general] 10=Inst Stage operate 162 99 1 2 0 1
Directional earth-fault protection (1 stage)
LD0.DEFLPTOC1.Str.general DEFLPDEF1.START Low stage start 10=Low Stage start 163 84 1 2 1 1
LD0.DEFLPTOC1.Op.general DEFLPDEF1.OPERATE Low stage operate 10=Low Stage operate 163 90 1 2 0 1
Phase currents limit supervison
LD0.CMMXU1.HiAlm.stVal CMMXU1.HIGH_ALARM Phase currents High alarm 10=High alarm 210 1 0 1 1 1
LD0.CMMXU1.HiWrn.stVal CMMXU1.HIGH_WARN Phase currents High warning 10=High warning 210 2 0 1 1 1
LD0.CMMXU1.LoWrn.stVal CMMXU1.LOW_WARN Phase currents Low warning 10=Low warning 210 3 0 1 1 1
LD0.CMMXU1.LoAlm.stVal CMMXU1.LOW_ALARM Phase currents Low alarm 10=Low alarm 210 4 0 1 1 1
Residual current limit supervision
LD0.RESCMMXU1.HiAlm.stVal
RESCMMXU1.HIGH_ALAR
M Residual current High alarm 10=High alarm 210 11 0 1 1 1
LD0.RESCMMXU1.HiWrn.stVal RESCMMXU1.HIGH_WARN Residual current High warning 10=High warning 210 12 0 1 1 1
Phase-to-phase voltage limit supervision
LD0.VMMXU1.HiAlm.stVal VMMXU1.HIGH_ALARM Ph-Ph voltage High alarm 10=High alarm 211 1 0 1 1 1
LD0.VMMXU1.HiWrn.stVal VMMXU1.HIGH_WARN Ph-Ph voltage High warning 10=High warning 211 2 0 1 1 1
LD0.VMMXU1.LoWrn.stVal VMMXU1.LOW_WARN Ph-Ph voltage Low warning 10=Low warning 211 3 0 1 1 1
LD0.VMMXU1.LoAlm.stVal VMMXU1.LOW_ALARM Ph-Ph voltage Low alarm 10=Low alarm 211 4 0 1 1 1
Residual voltage limit supervision
LD0.RESVMMXU1.HiAlm.stVal
RESVMMXU1.HIGH_ALAR
M Residual voltage High alarm 10=High alarm 211 11 0 1 1 1
LD0.RESVMMXU1.HiWrn.stVal RESVMMXU1.HIGH_WARN Residual voltage High warning 10=High warning 211 12 0 1 1 1
Circuit breaker position and failure protection
CTRL.CBCILO1.EnaOpn.stVal CBXCBR1.ENA_OPEN CB open enabled 10=Open enabled 240 21 1 1 1 1
CTRL.CBCILO1.EnaCls.stVal CBXCBR1.ENA_CLOSE CB close enabled 10=Close enabled 240 22 1 1 1 1
CTRL.CBXCBR1.BlkOpn.stVal CBXCBR1.BLK_OPEN CB open blocked 10=Open blocked 240 23 1 1 1 1
CTRL.CBXCBR1.BlkCls.stVal CBXCBR1.BLK_CLOSE CB close blocked 10=Close blocked 240 24 1 1 1 1
CTRL.CBCILO1.ItlByPss.stVal CBXCBR1.ITL_BYPASS CB interlocking bypass 10=Interlocking bypassed 240 25 1 1 1 1
CTRL.CCBRBRF1.Str.general CCBRBRF1.CB_FAULT_AL CBFP Start, timer running 10=Start,timer running 240 101 0 2 1 1
Table continues on next page
Section 2 1MRS756882 B
IEC 60870-5-103 data mappings
16 REM615
Point List Manual
