A071172 V3 EN
Figure 77: Cancelling operation
The time between selecting the object and giving a control command
is restricted by an adjustable time-out. When an object is selected, the
control command has to be given within this time.
With default configurations it is possible to control a breaker open
even when the breaker is in an intermediate state.
6.2.3 Controlling with the closing delay
Close delay mode and Close delay need to be set to be able to control objects with the
closing delay.
The closing operation from the LHMI can be delayed by a predefined period of time.
1.
Press to close the selected object.
•
If there are several controllable objects, select the object and press to
confirm the selection.
2.
To confirm the operation, select Yes and press .
• After the control operation is confirmed, the delay is activated.
• Cancel the control by pressing any key when the delay is active.
1MRS758754 B Section 6
Operating procedures
REC615 and RER615 97
Operation Manual
