Page #25 background image
Table 20. Electromagnetic compatibility tests, continued
Description Type test value Reference
Power frequency immunity test Binary inputs only IEC 61000-4-16
IEC 60255-26, class A
Common mode 300 V rms
Differential mode 150 V rms
Conducted common mode disturbances 15 Hz...150 kHz
Test level 3 (10/1/10 V rms)
IEC 61000-4-16
Emission tests EN 55011, class A
IEC 60255-26
CISPR 11
CISPR 12
Conducted
0.15...0.50 MHz <79 dB (µV) quasi peak
<66 dB (µV) average
0.5...30 MHz <73 dB (µV) quasi peak
<60 dB (µV) average
Radiated
30...230 MHz <40 dB (µV/m) quasi peak, measured at 10 m
distance
230...1000 MHz <47 dB (µV/m) quasi peak, measured at 10 m
distance
1…3 GHz <76 dB (µV/m) peak
<56 dB (µV/m) average, measured at 3 m
distance
3…6 GHz <80 dB (µV/m) peak
<60 dB (µV/m) average, measured at 3 m
distance
Table 21. Insulation tests
Description
Type test value Reference
Dielectric tests 2 kV, 50 Hz, 1 min
500 V, 50 Hz, 1 min, communication
IEC 60255-27
Impulse voltage test 5 kV, 1.2/50 μs, 0.5 J
1 kV, 1.2/50 μs, 0.5 J, communication
IEC 60255-27
Insulation resistance measurements >100 MΩ, 500 V DC IEC 60255-27
Protective bonding resistance <0.1 Ω, 4 A, 60 s IEC 60255-27
Table 22. Mechanical tests
Description
Requirement Reference
Vibration tests (sinusoidal) Class 2 IEC 60068-2-6 (test Fc)
IEC 60255-21-1
Shock and bump test Class 2 IEC 60068-2-27 (test Ea shock)
IEC 60068-2-29 (test Eb bump)
IEC 60255-21-2
Seismic test Class 2 IEC 60255-21-3
Capacitor Bank Protection and Control
1MRS757952 D
REV615
Product version: 5.0 FP1
ABB 25
