ABB REV615 User Manual

Table 2. Supported functions
Function IEC 61850 A B
Protection
Three-phase non-directional overcurrent protection, low stage PHLPTOC 1 1
Three-phase non-directional overcurrent protection, high stage PHHPTOC 2 2
Three-phase non-directional overcurrent protection, instantaneous stage PHIPTOC 1 1
Non-directional earth-fault protection, low stage EFLPTOC 2
Non-directional earth-fault protection, high stage EFHPTOC 1 1
Non-directional earth-fault protection, instantaneous stage EFIPTOC 1
Directional earth-fault protection, low stage DEFLPDEF 2
Directional earth-fault protection, high stage DEFHPDEF 1
Transient/intermittent earth-fault protection INTRPTEF
1
1)
Negative-sequence overcurrent protection NSPTOC 2 2
Residual overvoltage protection ROVPTOV 1
2
2)
Three-phase undervoltage protection PHPTUV 2
Three-phase overvoltage protection PHPTOV 2
Positive-sequence undervoltage protection PSPTUV 1
Negative-sequence overvoltage protection NSPTOV 1
Three-phase thermal overload protection, two time constants T2PTTR 1 1
Circuit breaker failure protection CCBRBRF 1 1
Master trip TRPPTRC 2
(3)
3)
2
(3)
3)
Arc protection ARCSARC (3) (3)
Multipurpose protection MAPGAPC 18 18
Three-phase overload protection for shunt capacitor banks COLPTOC 1 1
Current unbalance protection for shunt capacitor banks CUBPTOC
1
4)
1
4)
Three-phase current unbalance protection for shunt capacitor banks HCUBPTOC
1
4)
1
4)
Shunt capacitor bank switching resonance protection, current based SRCPTOC 1 1
Power quality
Current total demand distortion CMHAI
(1)
5)
(1)
6)
Voltage total harmonic distortion VMHAI
(1)
6)
Voltage variation PHQVVR
(1)
6)
Voltage unbalance VSQVUB
(1)
6)
Control
Circuit-breaker control CBXCBR 1 1
Disconnector control DCXSWI 2 2
Earthing switch control ESXSWI 1 1
Disconnector position indication DCSXSWI 3 3
Earthing switch indication ESSXSWI 2 2
Condition monitoring and supervision
Circuit-breaker condition monitoring SSCBR 1 1
Trip circuit supervision TCSSCBR 2 2
Current circuit supervision CCSPVC 1 1
Fuse failure supervision SEQSPVC 1
Runtime counter for machines and devices MDSOPT 1 1
Measurement
Disturbance recorder RDRE 1 1
Load profile record LDPRLRC 1 1
Fault record FLTRFRC 1 1
Three-phase current measurement CMMXU 1 1
Sequence current measurement CSMSQI 1 1
Residual current measurement RESCMMXU 1 1
Three-phase voltage measurement VMMXU 1
Residual voltage measurement RESVMMXU 2
Sequence voltage measurement VSMSQI 1
Three-phase power and energy measurement PEMMXU 1
Capacitor Bank Protection and Control
1MRS757952 D
REV615
Product version: 5.0 FP1
6 ABB
