ABB RHD Series Service Instruction

RHD250 to 4000 (Contrac) ELECTRICAL ROTARY ACTUATOR | SEI/RHD250/4000-EN REV. A 7
RHD oil types
Ambient temperature
Oil types - DIN 51517
Default oil filled with delivery
Alternative oil
−
10 to 65 °C (15 to 150 °F) Castrol Alpha BMP 220 –
DIN 51517
ESSO Spartan EP 220 – DIN 51517 / ISO 12925-
1
BP Energol GR-XP 220 – DIN
51517
Shell Omala 220 – DIN 51517 / ISO 12925-
1
Mobilgear 630 – DIN 51517 / ISO 12925-1
−
30 to 50 °C (−20 to 130 °F) Mobil SHC 629 – DIN 51517 / ISO 12925-
1
-
−1 to 85 °C (30 to 185 °F)
Mobil SHC 632 – DIN 51517 / ISO 12925-1
-
Filling volumes
RHD250
Mounting position
IMB 3
IMB 6
IMB 7
IMV 5
IMV 6 / IMB 8
Minimum oil level l
(gal)* Approx. 4.7
(1.24)
Approx. 4.7 (1.24)
Approx. 4.7 (1.24)
Approx. 4.7 (1.24)
Approx. 4.7 (1.24)
Minimum oil level under inspection
plug mm (in)
40 (1.57)
12 (0.47)
15 (0.59)
35 (1.38)
Lower edge of upper oil
plug
RHD500 / RHD800
Mounting position
IMB 3
IMB 6
IMB 7
IMV 5
IMV 6 / IMB 8
Minimum oil level l (gal)*
Approx. 10 (2.65)
Approx. 11.5 (3.04)
Approx. 10 (2.65)
Approx. 10 (2.65)
Approx. 10 (2.65)
Minimum oil level under inspection
plug mm (in)
57 (2.24)
Lower edge of upper oil
plug
15 (0.59)
37
(1.46)
Lower edge of upper oil
plug
RHD1250 / RHD2500
Mounting position
IMB
3
IMB
6
IMB
7
IMB
8
IMV
5
IMV
6
Minimum oil level l (gal)*
Approx. 29 (7.67)
Approx. 32 (8.47)
Approx. 24 (6.34)
Approx. 24 (6.34)
Approx. 33 (8.72)
Approx. 26.5 (7.01)
Minimum oil level under inspection
plug mm
(in)
75 (2.95)
90 (3.54)
200 (7.87)
Lower edge of upper oil plug.
Delivered filled with 33
l
(8.72
gal*).
34 (1.34)
35 (1.38)
RHD4000
Mounting position
IMB 3
IMB 6
IMB 7
IMB 8
IMV 5
IMV 6
Minimum oil level l (gal)*
Approx. 29 (7.67)
Approx. 32 (8.47)
Approx. 24.5 (6.47)
Approx. 24 (6.34)
Approx. 34 (8.98)
Approx. 26.5 (7.01)
Minimum oil level under inspection
plug mm
(in)
75 (2.95)
90 (3.54)
200 (7.87)
Lower edge of upper oil plug.
Delivered filled with 33
l
(8.72 gal*).
34 (1.34)
35 (1.38)
* US liquid gallon
